Pole Shaft: Our commercial grade fiberglass square poles are constructed of thermoset polyester resin containing "E" type fiberglass. The surface of the shaft is smooth and consists of a saturated polyester surfacing veil and a resin layer. The resin is unsaturated polyester containing UV inhibitor and pigment throughout. Urethane coating is applied to the surface of the pole shaft. The surfacing veil and structural fibers are saturated in a singular process with the same resin, ensuring molecular bonding between structural layers and the protective layer. Non-conductive, 70% lighter than steel, dent resistant and does not rust or corrode, making this pole easy to install and extra safe.
Handhole: 2.5 X 5 inches tall reinforced handhole is provided at 18 inches from the base. A cover with a single screw to secure the latch mechanism is also provided.
Base Cover: A 2 piece fiberglass base cover is included.
Anchor Bolts: A set of 4 steel anchor bolts are provided with each pole assembly. Each bolt includes 2 nuts and 2 washers. A portion of the anchor bolt is threaded for securing and leveling the pole with the provided nuts and washers. An actual size paper anchor bolt template is provided.
Color Options: Dark bronze, gray, white and black colors are provided at no extra charge. Custom color options are available at a surcharge.
Other Options: The following options are available; custom colors, custom pole heights, additional handholes and custom base plate dimensions. Please consult one of our light pole experts for details.
- POLE HEIGHT:
- 25 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- WIDTH OR DIAMETER:
- 4 Inch
