Product Description:
- Pole Top Options: A removable pole cap is provided. If tenon option is selected, a 2-3⁄8" diameter tenon with 4 inch length is provided.
- Pole Shaft: 12 ft. height tapered aluminum shaft with 0.125" wall thickness. The pole shaft is constructed of seamless extruded tube of 6063 Series Aluminum Alloy.
- Handhole: Reinforced 2"x4" handhole is located 18 inches above ground. Handhole cover with 2 screws is provided. A ground lug with set screw is located near the handhole opening for proper grounding of the pole.
- Finish: Brushed Natural Aluminum.
- Anchor Bolts: A set of 4 galvanized steel anchor bolts is provided with each pole assembly. Each anchor bolt includes 2 Hex Nuts and 2 Flat Washers. An actual size paper anchor bolt template is provided.
- Bolt Circle Range: 7 1/2"-8 1/2".
- Base Style: 4 Bolt Cast Aluminum Base Flange of Alloy 356-T6 with Aluminum Bolt Covers (Alloy 356-F) and Stainless Steel Hex Head Attaching Screws.
- Warranty: 5 years.
- Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
- POLE HEIGHT:
- 12 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- Round Tapered
- faq_category:
- aluminum-light-poles
- quick_shipping:
- true
- 5_year_warranty:
- true
- WIDTH OR DIAMETER:
- 5 Inch
- WALL THICKNESS:
- 0.125 Inch
- Product Note:
- In-stock!
