200 Watt LED Flood Light

Write a Review
Item #
710094
MSRP: $399.00
$285.00
(You save $114.00 )

Get A Free Quote
Item Number: 710094
Product Description
Best in class, commercial grade, outdoor rated 200 watt LED area light. Die-cast aluminum housing with anti-static powder coat paint in bronze. Built in aluminum fins maximize heat dissipation and trouble free operation. Easily replaces any 750-1,000 watt metal halide or 1,000 watt high pressure sodium light. Designed specifically for outdoor use such as parking lots and street lights. IP65 rating allows it to endure severe weather conditions for many years. Heavy duty adjustable bracket designed to fit 2 3/8 inch tenon is included. Direct pole mounting arm option is available. 5 year warranty.

Product Specifications
  • Power: 200 watt
  • Voltage: 120-277 volt
  • Delivered Lumens: 22,500
  • Lumens/Watt: 113
  • HID Equivalent:
    • 750 watt metal halide
    • 1,000 watt HPS
  • Color Temperature: 5000 K
  • CRI: >75
  • IP Rating: IP65 wet location
  • Material: Die-cast aluminum
  • Life Expectancy: 50,000 hours
  • Shorting Cap: Shorting cap is supplied for photocell receptacle
  • Dimming: No
  • Fixture Color: Dark bronze
  • Warranty: 5 years
  • Mounting: Adjustable 2 3/8 inch slip fitter
  • Power Factor: 0.945
  • Frequency: 50/60 hertz
  • Suggested Ambient Temperature: -30° to 140° F
  • Dimensions: 24 inch length X 11 inch width X 3.6 inch height
  • Weight: 20 lbs.
  • EPA: 1.1
  • Certification: UL Listed

Dimensional Drawing
“LED
