LED Light Poles System for Football Field Includes:
Four (4) Round Tapered Steel Light Poles with hardware, sets of anchor bolts, and base covers.
Four (4) Sports Light Packages Include (each):
- One (1) Exclusive Power Bar Bracket with Four (4) 75,000 Lumen LED Lights and Visors.
- Two (2) Exclusive Power Bar Brackets with Three (3) 75,000 Lumen LED Lights and Visors.
Power Bar Sports Lights Packages ship pre-wired and ready to mount. Easy installation or replacement with EZ twist/lock connectors.
Light Pole:
- Pole Shaft: Pole shaft shall be weldable-grade, cold-rolled, commercial quality carbon steel tubing conforming to ASTM standards 4 gauge. Pole height is 39 ft.
- Handhole: Reinforced, 3" x 5" Handhole with cover, stainless steel screw and backbar is located at 18 inches from the base. Ground lug is included.
- Finish: Commercial grade, super durable black powder coat over galvanized finish. Dark Bronze, White, Gray colors are provided at no extra charge. Other colors and custom colors are available with extended lead times and additional surcharge.
- Anchor Bolts: A set of 4 galvanized steel anchor bolts specifically designed for this light pole is required for each pole assembly. Each anchor bolt includes 2 nuts and 2 washers. The top portion of the anchor bolt is threaded for securing and leveling the pole with the provided nuts and washers. An actual size paper anchor bolt template is provided.
- Bolt Circle: 14.5" (Bolt Circle Range 14"-16")
- Base Cover: Two-piece steel square base cover is required for protecting pole base from elements. Stainless steel screws are included to attach the 2 pieces together after pole installation.
- Other Options: The following options are available at an extra charge: Custom tenon sizes, custom colors, electric/GFI outlets, custom pole heights, additional handholes and custom base plate dimensions.
- Warranty: 1 Year.
- Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
Each Sports Light Package Includes:
- One (1) Exclusive Power Bar Bracket with Four (4) 75,000 Lumen LED Lights and Visors.
- Two (2) Exclusive Power Bar Brackets with Three (3) 75,000 Lumen LED Lights and Visors.
Power Bar Sports Lights Packages ship pre-wired and ready to mount.
Mounting hardware is provided.
Easy installation or replacement with EZ twist/lock connectors.
LED Fixture:
- Material: Aluminum construction with integrated fins to maximize heat dissipation.
- Color: Black
- Power: 500 Watts
- Lumens: 75,000
- Lumens/Watt: 150
- Voltage: 120-277 Volt standard. 345-480 Volt option as special order
- Color Temperature: 5000K
- Dimming: 0-10V Dimming Capable. Dimming control not provided (field install).
- IP Rating: IP66
- UL Listed: Yes
- Life Expectancy: 180,000 Hours
- Weight: 25 lbs. (Each)
Four (4) Lights Bar:
Beam Angle: 45°
Total Power: 2000 Watts
Total Lumens: 75,000 x 4=300,000
Total Amps: 16.68 @120V / 7.24 @277V
Three (3) Lights Bar (each):
Beam Angle: 30°
Total Power: 1500 Watts
Total Lumens: 75,000 x 3=225,000
Total Amps: 12.51 @120V / 5.43 @277V
Total Power: 5000 Watts
Total Lumens: 75,000 x 10=750,000
Total Weight: 359 lbs.
Warranty: 5 Years
- POLE HEIGHT:
- 39 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- Round Tapered
- WIDTH OR DIAMETER:
- 9 Inch
- GAUGE:
- 7 Gauge
- WATTS:
- 500 Watts
- 1_stop_solution:
- true
- ul_listed:
- true
- wet_location:
- true
- dimmable:
- true
- ip66:
- true
- free_shipping:
- true
- Product Note:
- Free shipping!
- dlc:
- true
