Product Specifications:
- Pole Top Options: Open top is standard. Removable top cap or tenon is available as an option. 2-3/8” O.D. aluminum tenon is 4” high and is attached to the pole with 3 set screws.
- Pole Shaft: 3 inch round straight aluminum with 0.125” wall thickness. Seamlessly extruded from 6063-T6 alloy.
- Pole Height: Standard pole height is 14 ft. Optional heights are 12, 10 and 8 ft. Custom heights are also available.
- Decorative Base: 2-piece, clamshell style cast aluminum material. Cast aluminum collar is included for proper fitment of 3” OD pole into the base. 4 stainless steel, tamper-resistant screws are included for attachment.
- Weight: 17.5 lbs
- Handhole: 2” X 4” size handhole is located at 18 inches from the base. An aluminum handhole cover with 2 screws is provided. A ground lug with set screw is located near the handhole opening for proper grounding of the pole.
- Color: Black powder coat.
- Anchor Bolts: A set of 4 galvanized steel anchor bolts is provided with each pole assembly. Each anchor bolt includes 2 nuts and 2 washers. Top portion of the anchor bolt is threaded for securing and leveling the pole with the provided nuts and washers. An actual size paper anchor bolt template is provided.
- Maximum Load: Designed to support single light with a maximum weight of 25 lbs.
- Warranty: 5 Years.
- Use: To be used only as a light pole with single light fixture on top. Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
| POLE WIND RATING (EPA) with 1.3 Gust Factor | Pole Weight (lbs) | ||||
| Pole Height (ft) | 70 mph | 80 mph | 90 mph | 100 mph | |
| 8 | 6.3 | 4.5 | 3.0 | 2.0 | 14 |
| 10 | 5.0 | 3.6 | 2.4 | 1.6 | 16 |
| 12 | 4.2 | 3.0 | 2.0 | 1.3 | 19 |
| 14 | 3.4 | 2.4 | 1.6 | 1.0 | 21 |
- POLE HEIGHT:
- 8 Foot
- POLE HEIGHT:
- 10 Foot
- POLE HEIGHT:
- 12 Foot
- POLE HEIGHT:
- 14 Foot
- POLE HEIGHT:
- 16 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- Round
- WIDTH OR DIAMETER:
- 3 Inch
- WALL THICKNESS:
- 0.125 Inch
