Product Description:
- Pole Top Options: Open top is standard. Removable top cap or tenon is available as an option. 2 3/8” OD aluminum tenon is 4” high.
- Pole Shaft: 3 inch round straight aluminum with 0.125” wall thickness. Seamlessly extruded from 6063-T6 alloy.
- Pole Height: Pole height is 15 ft above grade.
- Handhole: 2 1/2” X 4” size handhole is located at 12 inches from the base. An aluminum handhole cover with 2 screws is provided.
- Finish: Commercial grade, super durable powder coat finish. Dark Bronze, Black, White, Gray colors are available.
- Embedment: Embedment length is 3 ft. A 1 3/4” X 5 3/4" size slotted opening is provided 18 inches from the ground line for conduit entry.
- Maximum Load: This light pole is designed to support a light with maximum weight of 40 lbs.
- Warranty: 5 Years.
- Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
- POLE HEIGHT:
- 15 Foot
- INSTALLATION TYPE:
- Direct Burial
- POLE SHAPE:
- Round
- faq_category:
- aluminum-light-poles
- 5_year_warranty:
- true
- WIDTH OR DIAMETER:
- 3 Inch
- WALL THICKNESS:
- 0.125 Inch
