20 Foot 5 Inch Square Steel Light Pole 7 Gauge. Item Number: 547111
Product Specifications
- Pole Top Options: A removable pole cap is provided.
- Pole Shaft: 5 inch square 7 gauge commercial grade steel conforms to ASTM standards. Pole height is 15 ft.
- Handhole: Reinforced, 3” X 5” size handhole is located at 18 inches from the base. Grounding lug incorporating a tapped 1/2"-13 NC hole is provided.
- Color: Dark Bronze
- Anchor Bolts: A set of 4 galvanized steel anchor bolts specifically designed for this light pole is required for each pole assembly. Each anchor bolt includes 2 nuts and 2 washers. The top portion of the anchor bolt is threaded for securing and leveling the pole with the provided nuts and washers. An actual size paper anchor bolt template is provided.
- Bolt Circle: 11" (Bolt Circle Range 10"-12")
- Base Cover: Two-piece ABS plastic base cover is included.
- Warranty: 1 Year.
- Foundation Design: Foundation should be designed by an engineer familiar with local so and wind conditions as well as local code where the pole(s) will be installed.
- POLE HEIGHT:
- 15 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- Square
- WIDTH OR DIAMETER:
- 5 Inch
- GAUGE:
- 7 Gauge
- faq_category:
- steel-light-poles
- Product Note:
- While quantities last, first come first served, all sales final, no returns, no modifications.
