Advanced Anchor Base Adapter

Item #
AABA
  • Dark Bronze - Standard
  • Black Powder Coat + $50
  • White Powder Coat + $50
  • Gray Powder Coat + $50
  • Custom Color: Contact LightMart
$225.00

Get A Free Quote
Product Description:Built like a tank, this adapter is the best solution when you light pole's base plate doesn't line up with your existing anchor bolt foundation. The adapter works with bolt circles ranging from 7 inches to 14-3/4 inches. You can use this adapter to easily solve your anchor bolt alignment problem as long as the bolt circle of the pole and the foundation is a minimum of 7 inches and a maximum of 14-3/4 inches. For example: If the existing anchor bolt circle is 12 inches but the pole you will be erecting has a bolt circle of 8.5 inches, this advanced anchor base adapter will solve the problem!
Product Features:
  • Proudly engineered and manufactured by LightMart in the USA
  • Industrial grade powder coat for resistance against tough weather conditions
  • Works with 3/4 inch or 1 inch anchor bolts
  • Set of heavy-duty bolts, washers and nuts are included to attach the pole to this adapter
  • No need to drill or pour a new base, the Advanced Anchor Bolt Adapter saves time and money
  • Weighs 52 lbs.

The Advanced Anchor Base Adapter is not recommended for use with light poles over 40-feet tall.

Dimensional Drawing: AABA-Dimensional-Drawing
