Pole Top Options: Open top is standard. Removable top cap or tenon is available as an option. 2-3/8" O.D. aluminum tenon is 4" high and is attached to the pole with 3 set screws.
Pole Shaft: 3 inch round straight aluminum with 0.125" wall thickness. Seamlessly extruded from 6063-T6 alloy.
Pole Height: Standard pole height is 14 ft. Optional heights are 12, 10 and 8 ft. Custom heights are also available.
Handhole: 2" X 4" size handhole is located at 18 inches from the base. An aluminum handhole cover with 2 screws is provided. A ground lug with set screw is located near the handhole opening for proper grounding of the pole.
Color: Black powder coat.
Anchor Bolts: A set of 4 galvanized steel anchor bolts is provided with each pole assembly. Each anchor bolt includes 2 nuts and 2 washers. Top portion of the anchor bolt is threaded for securing and leveling the pole with the
provided nuts and washers. An actual size paper anchor bolt template is provided.
Base Cover: An optional two-piece base cover is available for additional cost. Hardware is included to securely attach the two pieces together after pole
installation.
Maximum Load: Designed to support single light with a maximum weight of 25 lbs.
Warranty: 5 Years.
Use: To be used only as a light pole with single light fixture on top.
Foundation Design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
| POLE WIND RATING (EPA) with 1.3 Gust Factor | Pole Weight (lbs) | ||||
| Pole Height (ft) | 70 mph | 80 mph | 90 mph | 100 mph | |
| 8 | 6.3 | 4.5 | 3.0 | 2.0 | 14 |
| 10 | 5.0 | 3.6 | 2.4 | 1.6 | 16 |
| 12 | 4.2 | 3.0 | 2.0 | 1.3 | 19 |
| 14 | 3.4 | 2.4 | 1.6 | 1.0 | 21 |
Advantages of the Round Aluminum Light Pole
- Versatile Height Options: Available in heights of 8, 10, 12, and 14 feet, accommodating various outdoor lighting needs.
- Corrosion-Resistant Material: Made from 6063-T6 aluminum, ensuring long-term durability and minimal maintenance in outdoor conditions.
- Easy Installation: Includes pre-drilled holes, galvanized steel anchor bolts, and an optional base cover for streamlined setup.
- Lightweight Design: Aluminum construction makes handling and installation easier compared to steel poles.
- Customizable Features: Options for open top, removable top caps, or tenons allow compatibility with different light fixtures.
Applications for the Round Aluminum Light Pole
Designed for versatility, this lighting system is ideal for a range of court settings, including:
- Commercial Parking Lots and Pathways: Reliable lighting for safety and security.
- Recreational Parks: Suitable for public areas requiring long-lasting, low-maintenance solutions.
- Industrial Complexes: Capable of supporting lighting systems in harsh environments.
- POLE HEIGHT:
- 8 Foot
- POLE HEIGHT:
- 10 Foot
- POLE HEIGHT:
- 12 Foot
- POLE HEIGHT:
- 14 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- Round
- WIDTH OR DIAMETER:
- 3 Inch
- WALL THICKNESS:
- 0.125 Inch
- faq_category:
- aluminum-light-poles
- quick_shipping:
- true
- 5_year_warranty:
- true
- Product Note:
- This light pole may not be suitable for use in high-wind areas.
