Round Aluminum Light Pole, 8-16 Foot, 4 Inch Diameter, Anchor Base, Quick Ship

Item #
QS4ALAB
This light pole may not be suitable for use in high-wind areas.
$459.00

Get A Free Quote
  • Pole Top Options: Open top is standard. Removable top cap or tenons are available as options. Tenon options: 2-3/8”O.D. or 3” O.D. 4 inch height is standard.
  • Pole Shaft: 4 inch round straight aluminum with 0.125” wall thickness. Seamlessly extruded from 6063-T6 alloy.
  • Pole Height: Standard pole height is 16 ft. Optional heights are 14, 12, 10 and 8 ft. Custom heights are also available.
  • Handhole: 2-1/2” X 4” size handhole is located at 18 inches from the base. An aluminum handhole cover with 2 screws is provided. A ground lug with set screw is located near the handhole opening for proper grounding of the pole.
  • Color: Black powder coat.
  • Anchor Bolts: A set of 4 galvanized steel anchor bolts is provided with each pole assembly. Each anchor bolt includes 2 nuts and 2 washers. Top portion of the anchor bolt is threaded for securing and leveling the pole with the provided nuts and washers. An actual size paper anchor bolt template is provided.
  • Base Cover: An optional two-piece base cover is available for an additional charge.
  • Maximum Load: Designed to support single light with a maximum weight of 30 lbs.
  • Warranty: 5 Years.
  • Use: To be used only as a light pole with single light fixture on top.
  • Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
POLE WIND RATING (EPA) with 1.3 Gust Factor Pole Weight (lbs)
Pole Height (lbs) 70 mph 80 mph 90 mph 100 mph
8 6.5 4.5 3.2 2.0 17
10 5.6 3.9 2.7 1.7 21
12 4.7 3.3 2.2 1.4 24
14 3.7 2.6 1.8 1.1 28
16 3.2 2.3 1.7 1.0 32
POLE HEIGHT:
8 Foot
POLE HEIGHT:
10 Foot
POLE HEIGHT:
12 Foot
POLE HEIGHT:
14 Foot
POLE HEIGHT:
15 Foot
POLE HEIGHT:
16 Foot
INSTALLATION TYPE:
Anchor Base
POLE SHAPE:
Round
WIDTH OR DIAMETER:
4 Inch
WALL THICKNESS:
0.125 Inch
faq_category:
aluminum-light-poles
quick_shipping:
true
10_year_warranty:
true
Product Note:
This light pole may not be suitable for use in high-wind areas.
