Windsor Series, 4 inch Round Aluminum Light Pole Assembly Direct Burial

Item #
70174
$629.00

Get A Free Quote
Product Specifications:
  • Pole: 4 inch round straight aluminum with 0.125” wall thickness. Conforms to ASTM B221 with extruded 6063 aluminum heat treated post welding to T6 temper. Shaft is free of longitudinal welds.
  • Embedment: This pole gets embedded directly into the ground and does not require any anchor bolts. Typical embed length is 3 foot below grade. A 1.5 inch grommeted cable entry is provided 18 inches below grade.
  • Pole Top: Removable pole cap, 2 3/8 inch tenon and 3 inch shaft options are available.
  • Decorative Base: Single piece cast aluminum base slides over the pole before light fixture is attached to pole. Black powder coat, no other color options are available.
  • Color: Entire assembly is powder coated in black, no other color options are available.
  • Handhole: 2-1/2” X 4” size handhole is located at 18 inches from the base.

Wind Speed
Pole Height
70 mph
80 mph
90 mph
100 mph
8 foot
6.3
4.5
3.0
2.0
10 foot
5.0
3.6
2.4
1.6
12 foot
4.2
3.0
2.0
1.3
15 foot
2.9
2.1
1.4
0.9


Product Dimensions
  • Decorative Base Height: 33.1 inches
  • Decorative Base Width: 9.3 inches
  • Aluminum Pole Diameter: 4 inches
  • Available Overall Heights: 8, 10, 12 and 15 foot. Custom heights not exceeding 15 foot are available.

POLE HEIGHT:
8 Foot
POLE HEIGHT:
10 Foot
POLE HEIGHT:
12 Foot
POLE HEIGHT:
15 Foot
INSTALLATION TYPE:
Direct Burial
POLE SHAPE:
Round
WIDTH OR DIAMETER:
4 Inch
WALL THICKNESS:
0.125 Inch
faq_category:
aluminum-light-poles
10_year_warranty:
true
