12 Foot Hurricane Resistant Square Aluminum Pole, 4 Inch Wide, 0.125 Inch Wall Thickness

Item #
H12A4SS125
  • Dark Bronze Powder Coat (Standard)
  • Black Powder Coat +$60
  • White Powder Coat +$60
  • Gray Powder Coat +$60
$719.00

Get A Free Quote

Availability: This is a made to order item. We will contact you with current lead time within one business day of order placement. For poles that can ship in a few days please visit our quick-ship poles section: quick-ship light poles.

Material: This hurricane resistant square aluminum light pole is 12 feet high and 4 in. wide from top to bottom with a wall thickness of 0.125 and maximum EPA rating of 3.7 at 180 mph (based on AASHTO 2009 design standards). To see the full specifications for our 12 foot 4 inch hurricane resistant square aluminum light pole 0.125, please click on the highlighted text. Our aluminum light poles are designed to American Association of State Highway & Transportation Officials (AASHTO) standards and meet all applicable material ASTM standards. All welders are American Welding Society (AWS) certified.

Anchor Bolts and Handhole Covers: This light pole includes anchor bolts made of galvanized steel (Grade 55 meeting AASHTO M314-90 standard) with a bolt circle diameter of 8.5 to 9.5 in.. A base flange with bolt covers, reinforced handhole with cover, and stainless steel hex-head screws are also included. For your convenience, anchor bolts can be pre-shipped for a nominal surcharge. Bolt Circle: Bolt circle diameter of 8.5 – 9.5 in..

Pole Drilling Options: We can drill our aluminum light poles to your specifications at no extra charge. We offer such a large variety of drilling options that should you need anything other than our standard drill template shown in the images above and different drill orientation (also shown above), please contact one of our engineers at 1-800-443-8254 or e-mail them at: [email protected] com.

Color Options: Standard color is Dark Bronze; however, we provide Black, White, and Gray for an additional charge. Our thermoset powder coat process is in accordance with AAMA 2604 classification and is much superior to AAMA 2603 used by other manufacturers.

Pole Accessories: We offer an extensive list of OEM accessories for our aluminum light poles ranging from transformer bases and GFI receptacle outlets to vibration dampeners. In addition, we do not charge extra for cutting our poles to custom lengths in case what we offer requires customization

Warranty: We are so confident that our aluminum light poles are the best that we offer an industry leading 10 year warranty.



Maximum EPA with 1.3 Gust Factor (ft²) Pole Weight (lbs
120 mph 140 mph 160 mph 180 mph
5.6 3.6 2.3 1.4 35
POLE HEIGHT:
12 Foot
INSTALLATION TYPE:
Anchor Base
POLE SHAPE:
Square
WIDTH OR DIAMETER:
4 Inch
WALL THICKNESS:
0.125 Inch
HURRICANE RESISTANT:
Yes
made_in_usa:
true
10_year_warranty:
true
faq_category:
aluminum-light-poles
