Pole Top Options: A removable pole cap or open top are standard options. Available tenon diameter options are: 2-3/8 in. or 3 in. Both tenon options are 4 in. long.
Pole Shaft: The pole shaft is constructed of seamless extruded tube of 6063 Series Aluminum Alloy per the requirements of ASTM B221.
Handhole: 2 in. X 4 in. size handhole with cover is located at 18 in. from the base. Ground lug is included.
Finish: Commercial grade, super durable powder coat finish. Black is standard color. Dark Bronze, White, Gray colors are available with extended lead times.
Anchor Bolts: A set of 4 galvanized steel anchor bolts is provided with each pole assembly. Each anchor bolt includes 2 Hex Nut, 2 Lock Washer and 2 Flat Washer. An actual size paper anchor bolt template is provided.
Bolt Circle Range: 6 1/2 "-8"
Base Cover: Two-piece ABS plastic base cover is provided. Hardware is included to securely attach the two pieces together after pole installation.
Other Options: The following options are available with extended lead times and surcharges: Vibration damper, custom tenon sizes, custom colors, electric/GFI outlets, custom pole heights, additional handhole and UL compliant handholes.
Warranty: 10 Years.
Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
- POLE HEIGHT:
- 12 Foot
- INSTALLATION TYPE:
- Anchor Base
- POLE SHAPE:
- Round
- WIDTH OR DIAMETER:
- 4 Inch
- WALL THICKNESS:
- 0.125 Inch
- made_in_usa:
- true
- 10_year_warranty:
- true
- faq_category:
- aluminum-light-poles
