14 Foot Round Straight Aluminum Light Pole, 4 Inch Diameter, 0.125 Inch Wall Thickness

Item #
14A4RS125
  • Black Powder Coat (Standard)
  • Dark Bronze Powder Coat +$60
  • White Powder Coat +$60
  • Gray Powder Coat +$60
$653.00

Get A Free Quote

Pole Top Options: A removable pole cap or open top are standard options. Available tenon diameter options are: 2-3/8 in. or 3 in. Both tenon options are 4 in. long.

Pole Shaft: The pole shaft is constructed of seamless extruded tube of 6063 Series Aluminum Alloy per the requirements of ASTM B221.

Handhole: 2 in. x 4 in. size handhole with cover is located at 18 in. from the base. Ground lug is included.

Finish: Commercial grade, super durable powder coat finish. Black is standard color. Dark Bronze, White, Gray colors are available with extended lead times and additional surcharge.

Anchor Bolts: A set of 4 galvanized steel anchor bolts is provided with each pole assembly. Each anchor bolt includes 1 Hex Nut, 1 Lock Washer and 1 Flat Washer. Energy Light, Inc. recommends leveling shims instead of leveling nuts. No grouting is required with leveling shims. Shims are available at a surcharge. An (actual size) paper anchor bolt template is provided.

Bolt Circle Range: 6-1/2 in. – 8 in.

Other Options: The following options are available with extended lead times and surcharges: Vibration damper, custom tenon sizes, custom colors, electric/GFI outlets, custom pole heights, additional handhole and UL compliant handholes.

Warranty: 10 Years.

Foundation Design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.



Maximum EPA with 1.3 Gust Factor (ft²) Pole Weight (lbs)
90 mph 100 mph 120 mph 130 mph
4.4 3.1 1.9 1.3 29
POLE HEIGHT:
14 Foot
INSTALLATION TYPE:
Anchor Base
POLE SHAPE:
Round
WIDTH OR DIAMETER:
4 Inch
WALL THICKNESS:
0.125 Inch
made_in_usa:
true
10_year_warranty:
true
faq_category:
aluminum-light-poles
